Zabbix Proxy RAM config

Content is copyed from ZNIL.NET

2.1 Install Raspbian

You download NOOBS:

5 Configure the Zabbix proxy

We open the configuration file

nano /etc/zabbix/zabbix_proxy.conf

and adjust at least the following lines:

Server = IP or DNS name of the Zabbix server to be reported to
# Hostname -> under this name we also have to create the proxy on the main server!
Hostname = zabbixproxy
# Increase command timeout. This is how long the proxy waits for replies from scripts, checks and agents
Timeout = 30
# New 3.4 feature - RemoteCommands now also work behind proxies
EnableRemoteCommands = 1
LogRemoteCommands = 1
# Database and log in the RAM disk (do not change the lines if not desired)
LogFile = / var / ramdisk / zabbix_proxy.log
LogFileSize = 4
DBName = / var / ramdisk / zabbixproxy.db

https://www.raspberrypi.org/downloads/noobs/

I recommend the normal variant, not the Lite - especially if you are on the go in company networks. Noobs (resp. Linux) zicks around if your DHCP server, for example, also distributes routes and then gets no internet connection. With the normal version you can always install Raspbian, even without an internet connection.

The microSD card must be formatted with FAT32. You could easily check this by going to the drive with the microSD card in File Explorer and calling the properties with the right mouse button:

2.2 Set fixed IP address

We log on to the Raspberry Pi and switch to root:

sudo -i

From the Raspbian stretch release, the IP address is specified in the following file (which we are processing):

nano /etc/dhcpcd.conf

Inserts the following lines there / changes the existing ones:

interface eth0
static ip_address = 10.100.20.166 / 24
static routers = 10.100.20.1
static domain_name_servers = 10.100.50.50 8.8.8.8

If you want to set the WLAN interface: just wlan0take it instead eth0(or additionally).
Save and restart the Raspberry:

reboot

2.3 restore root

I personally always work directly as root on the devices (always this sudo ...).
So that he can log in again - initially locally - he only needs a password:

sudo passwd root

and then 2 x the new password.

I also prefer the colored display of the bash prompt (as with user pi) and the use of aliases such as ll :

sudo cp /home/pi/.bashrc / root /
nano /root/.bashrc

and adjust the following lines:

# some more ls aliases
alias ll = 'ls -l'
alias la = 'ls -A'
alias l = 'ls -CF'

2.4 root login via SSH

2.4.2 By password

I am writing very thickly here:
NOT RECOMMENDED
but you know what you are doing:

sudo nano / etc / ssh / sshd_config

and find the following line and change it accordingly:

#PermitRootLogin prohibit-password
change to
PermitRootLogin yes

Then restart Raspberry and it should work.

2.4.1 Via SSH key

The root can already log in via SSH - but not with a password. I use PuTTY or KiTTY and so I simply leave the corresponding key.
You can find detailed instructions on how to set this up here if required

Ubuntu_16.04.x_2-factor_in_SSH_mit_Google_Authenticator_einrichten # R.C3.BCckversicherung_mit_SSH-Key

If you already have the key:

sudo -i
mkdir ~ / .ssh
chmod 700 ~ / .ssh
touch ~ / .ssh / authorized_keys2
chmod 600 ~ / .ssh / authorized_keys2

and then insert the key into the file:

nano ~ / .ssh / authorized_keys2

Now you can log in - using the SSH key - directly to the Raspberry using SSH.

2.5 Import updates

log back in as root
Search for updates for operating system: (updates the catalog from the update sources)

apt update

Import updates:

apt upgrade -y

Remove unnecessary packages after update:

apt autoremove -y

2.6 Firmware updates

rpi update

and wait + restart

2.7 Install the required programs for Zabbix

The following packages are not installed automatically, at least this creates missing log entries:

apt install -y snmp-mibs-downloader

3 Install the Zabbix Proxy

In the meantime I always install Zabbix directly from the repository https://repo.zabbix.com
And there are also corresponding installation files for ARM processors + Debian.

We add the package sources (Rasbian Stretch):

For version 4.0.x

wget wget https://repo.zabbix.com/zabbix/4.0/raspbian/pool/main/z/zabbix-release/zabbix-release_4.0-2+stretch_all.deb
dpkg -i zabbix-release_4.0-2 + stretch_all.deb
apt update

Note: Version 3.0 is already available in Raspbian Stretch. Then just leave out the sources

And now the proxy with SQLite support

apt install -y zabbix-proxy-sqlite3 zabbix-agent zabbix-sender zabbix-get

The configuration files are now under

/ etc / zabbix /

The Zabbix user has already been created, the start scripts for systemd are in the right places.

4 RAM disk for the database

The proxy collects the data from its area and forwards it centrally to the Zabbix server. Nevertheless, each value is first written to a local database and then sent. By default, the values are deleted from the database immediately, in the event of connection problems after one hour. You can see that in the log, there are corresponding maintenance entries:

483: 20180131: 141236.892 housekeeper [deleted 3981 records in 0.032466 sec, idle for 1 hour (s)]

The proxy is constantly in the process of writing values to the database, cleaning up once an hour. With the increased use of Raspberry Pi as a Zabbix proxy, the microSD cards have now always died after one year. This is certainly related to the size of the microSD card on the one hand, and the number of items that run through the proxy on the other.
After a while, the database itself reaches a fixed size, usually only a few MByte.
In connection with Zabbix, the database of the Zabbix proxy has two special features:

It is actually unimportant - the data is only buffered if the connection to the server is interrupted
If the Zabbix proxy is used with SQLite, it automatically creates this database including the schema - if it does not exist

The idea is to simply put the database in a RAM disk. A Raspberry Pi 2 (512MByte) or 3/3 + (1024MByte) can easily rip off 100Mbyte for this.
And we also put the logs in with it.
In practice, 100 MB is probably much too large - but (almost) never too small.

nano / etc / fstab

and add the following line:

tmpfs / var / ramdisk tmpfs nodev, nosuid, relatime, size = 100M 0 0

Then create the folder:

mkdir / var / ramdisk

and set the rights

chmod 0777 / var / ramdisk

With

mount -a
df -h

we can test whether the RAM disk is created.
Then perform a reboot and check whether it is available afterwards.

5 Configure the Zabbix proxy

We open the configuration file

nano /etc/zabbix/zabbix_proxy.conf

and adjust at least the following lines:

Server = IP or DNS name of the Zabbix server to be reported to
# Hostname -> under this name we also have to create the proxy on the main server!
Hostname = zabbixproxy
# Increase command timeout. This is how long the proxy waits for replies from scripts, checks and agents
Timeout = 30
# New 3.4 feature - RemoteCommands now also work behind proxies
EnableRemoteCommands = 1
LogRemoteCommands = 1
# Database and log in the RAM disk (do not change the lines if not desired)
LogFile = / var / ramdisk / zabbix_proxy.log
LogFileSize = 4
DBName = / var / ramdisk / zabbixproxy.db

6 Set up automatic start at boot

systemctl enable zabbix-proxy.service

7 Start Zabbix proxy testing

systemctl start zabbix-proxy

The log file and the database should now be in the RAM disk:

ls -l / var / ramdisk /

Output:

  3501: 20180131: 160550.657 Starting Zabbix Proxy (active) [TestPiProxy]. Zabbix 3.4.4 (revision 74338).
  3501: 20180131: 160550.657 **** Enabled features ****
  3501: 20180131: 160550.657 SNMP monitoring: YES
  3501: 20180131: 160550.657 IPMI monitoring: YES
  3501: 20180131: 160550.657 Web monitoring: YES
  3501: 20180131: 160550.657 VMware monitoring: YES
  3501: 20180131: 160550.657 ODBC: YES
  3501: 20180131: 160550.657 SSH2 support: YES
  3501: 20180131: 160550.657 IPv6 support: YES
  3501: 20180131: 160550.657 TLS support: YES
  3501: 20180131: 160550.657 **************************
  3501: 20180131: 160550.658 using configuration file: /etc/zabbix/zabbix_proxy.conf
  3501: 20180131: 160550.658 cannot open database file "/var/ramdisk/zabbixproxy.db": [2] No such file or directory
  3501: 20180131: 160550.658 creating database ...
  3501: 20180131: 160551.019 current database version (mandatory / optional): 03040000/03040005
  3501: 20180131: 160551.019 required mandatory version: 03040000
  3501: 20180131: 160551.057 proxy # 0 started [main process]
  3502: 20180131: 160551.059 proxy # 1 started [configuration syncer # 1]
  3504: 20180131: 160551.061 proxy # 3 started [data sender # 1]
  3506: 20180131: 160551.064 proxy # 5 started [http poller # 1]
  3503: 20180131: 160551.071 proxy # 2 started [heartbeat sender # 1]
  3505: 20180131: 160551.073 proxy # 4 started [housekeeper # 1]
  3509: 20180131: 160551.074 proxy # 8 started [history syncer # 2]
  3513: 20180131: 160551.078 proxy # 12 started [task manager # 1]
  3514: 20180131: 160551.080 proxy # 13 started [poller # 1]
  3507: 20180131: 160551.081 proxy # 6 started [discoverer # 1]
  3511: 20180131: 160551.086 proxy # 10 started [history syncer # 4]
  3517: 20180131: 160551.087 proxy # 16 started [poller # 4]
  3508: 20180131: 160551.091 proxy # 7 started [history syncer # 1]
  3510: 20180131: 160551.093 proxy # 9 started [history syncer # 3]
  3512: 20180131: 160551.101 proxy # 11 started [self-monitoring # 1]
  3515: 20180131: 160551.102 proxy # 14 started [poller # 2]
  3518: 20180131: 160551.102 proxy # 17 started [poller # 5]
  3516: 20180131: 160551.111 proxy # 15 started [poller # 3]
  3519: 20180131: 160551.112 proxy # 18 started [unreachable poller # 1]
  3523: 20180131: 160551.120 proxy # 22 started [trapper # 4]
  3524: 20180131: 160551.121 proxy # 23 started [trapper # 5]
  3520: 20180131: 160551.141 proxy # 19 started [trapper # 1]
  3525: 20180131: 160551.151 proxy # 24 started [icmp pinger # 1]
  3521: 20180131: 160551.152 proxy # 20 started [trapper # 2]
  3522: 20180131: 160551.161 proxy # 21 started [trapper # 3]
  3502: 20180131: 160551.749 received configuration data from server at "test.leitungsen.de", data 3401

If it says something like:

3586: 20180131: 160848.872 cannot send heartbeat message to server at "ecetest.leitungsen.de": proxy "TestPiProxy" not found
3585: 20180131: 160849.468 cannot obtain configuration data from server at "ecetest.leitungsen.de": empty string received

Well, we have to put the proxy on our Zabbix server

Administration - proxies

still create - please use the exact same name as the zabbix_proxy.confone Hostname=below - then the error is gone.

8 Configure and start the agent

We also want to monitor the proxy itself.
This too - as a host - must be created on the Zabbix server. The host name must be stored in the configuration file.
By default, the agent tries to return from the hostname command:

hostname

Output:

PiProxy01

Adaptation of the configuration:

nano /etc/zabbix/zabbix_agentd.conf

Changes:

# The name of the host on the Zabbix server
Hostname = PiProxy01
# Log file in the RAM disk
LogFile = / var / ramdisk / zabbix_agentd.log
LogFileSize = 1
# Timeout for queries / scripts etc.
Timeout = 30
# Allow special characters in the item keys
UnsafeUserParameters = 1
# Execute commands on call
EnableRemoteCommands = 1
LogRemoteCommands = 1

Activate automatic start at boat:

systemctl enable zabbix-agent.service

and start the agent:

systemctl start zabbix-agent.service

The log file shows the status

cat /var/ramdisk/zabbix_agentd.log

9 Reboot test

Reboots the system once

reboot

and checks if

The ramdisk was created
The Zabbix proxy has started, has created the database and the log file
The agent has started and created the log file
